Graffunder Safe & Vault

Weapon and Multipurpose Safes

Series: B,C,E,F

B-RATE CONSTRUCTION: 1 3/4" overall body constructed of 1/4" A36 high tensile steel outer and 16 ga. inner plates enclosing a high density composite material. 3 1/2" overall door insulated with U.L. approved insulating material, outer plate being 1/2" thick A36 high tensile steel.
C-RATE CONSTRUCTION: 2" overall body constructed of 1/2" A36 high tensile steel outer and 16 ga. inner plates enclosing a high density composite material. 4" overall door insulated with U.L. approved insulating material, outer plate being 1" thick A36 high tensile steel
E-RATE CONSTRUCTION: 2 1/2" overall body constructed of 1" A36 high tensile steel outer and 16 ga. inner plates enclosing a high density composite material. 4 1/2" overall door insulated with U.L. approved insulating material, outer plate being 1 1/2" thick A36 high tensile steel
F-RATE CONSTRUCTION: 2 1/2" overall body constructed of 1" A36 high tensile steel outer and 16 ga. inner plates enclosing a high density composite material. 4 1/2" overall door insulated with U.L. approved insulating material, outer plate being 1" thick A36 high tensile steel and 1/2" Manganese
1 - hour 1750 degree factory fire rating
8 to 10 solid 1 1/4" steel locking bolts, active front and back to prevent door removal after hinge attack
U.L. listed group II combination lock, with re-lock and 1 million possible combinations
Additional relocking devices activated by tool and/or torch attack for added security
Lock protected by Ball Bearing Anti Drill Barriers
Fully recessed, tightly toleranced door for protection against forced entry
High temperature heat seal door jam with additional intumescent fire and smoke seal
Hardened hinge pins that ride on thrust bearing washers
Attractive paint finishes to choose from
Variety of interiors to choose from
All safes covered by limited lifetime warranty
Model designations (see below): B = B-rated, C = C-rated, E = E rated, and F= F rated

ADDITIONAL FEATURES OF E and F RATE AS FOLLOWS:

U.L. approved Group 1 & 1R manipulation proof lock
Additional anti-drill barrier.
Hardened ball bearing anti-drill barrier protects bolts from punching attack
Graffunder Vault Doors are also available in the E rating and F rating.

Please contact us for more details. Any model can be designed to your specifications. Graffunder Safe and Vault, Inc. can also manufacture safes and vault doors at higher burglary and fire ratings.

	Exterior				Volumes (cu ft)		Gun Capacity by Interior setup
Model	W	H	D	Weight	Ext	Int	2	3	4	5	6S	6E	6C
B6026	26	58.5	23.25	1225	20	12	9	21	12	12	18	24	21
B6028	28	58.5	29.25	1490	27	18	16	32	16	16	32	32	32
B6032	32	58.5	23.25	1500	25	16	15	27	12	24	24	24	24
B6040	40	58.5	27.50	1790	37	25	24	48	14	28	40	32	36
B7232	32	70.5	23.25	1670	30	19	15	27	12	24	24	24	24
B7240	40	70.5	27.50	2100	44	30	24	48	14	28	40	32	36
B7248	48	70.5	27.50	2340	53	37	32	64	28	48	48	48	48

	Exterior				Volumes (cu ft)		Gun Capacity by Interior setup
Model	W	H	D	Weight	Ext	Int	2	3	4	5	6S	6E	6C
C6026	26.5	59	23.75	1800	21	12	9	21	12	12	18	24	21
C6028	28.5	59	30.00	2400	29	18	16	32	16	16	32	32	32
C6032	32.5	59	23.75	2070	26	16	15	27	12	24	24	24	24
C6040	40.5	59	28.25	2825	39	25	24	48	14	28	40	32	36
C7232	32.5	71	24.00	2420	32	19	15	27	12	24	24	24	24
C7240	40.5	71	28.25	3025	47	30	24	48	14	28	40	32	36
C7248	48.5	71	28.25	3600	56	37	32	64	28	48	48	48	48

	Exterior				Volumes (cu ft)		Gun Capacity by Interior setup
Model	W	H	D	Weight	Ext	Int	2	3	4	5	6S	6E	6C
E6026	27.5	60	25.00	2700	23	12	9	21	12	12	18	24	21
E6028	29.5	60	31.00	3700	31	18	16	32	16	16	32	32	32
E6032	33.5	60	25.00	3200	29	16	15	27	12	24	24	24	24
E6040	41.5	60	29.25	3900	42	25	24	48	14	28	40	32	36
E7232	33.5	72	25.00	4200	34	19	15	27	12	24	24	24	24
E7240	41.5	72	29.25	4800	50	30	24	48	14	28	40	32	36
E7248	49.5	72	29.25	5400	60	37	32	64	28	48	48	48	48

	Exterior				Volumes (cu ft)		Gun Capacity by Interior setup
Model	W	H	D	Weight	Ext	Int	2	3	4	5	6S	6E	6C
F6026	27.5	60	25.00	2700	23	12	9	21	12	12	18	24	21
F6028	29.5	60	31.00	3700	31	18	16	32	16	16	32	32	32
F6032	33.5	60	25.00	3200	29	16	15	27	12	24	24	24	24
F6040	41.5	60	29.25	3900	42	25	24	48	14	28	40	32	36
F7232	33.5	72	25.00	4200	34	19	15	27	12	24	24	24	24
F7240	41.5	72	29.25	4800	50	30	24	48	14	28	40	32	36
F7248	49.5	72	29.25	5400	60	37	32	64	28	48	48	48	48
